鋁合金門窗加工設備合片機用垂直定位機構托板固定在托板支板上，在托板支板的下面有兩個升降缸，升降缸是由升降缸導軸外套升降缸導套構成，托板支板就固定在兩升降缸導套上，在兩升降缸導套的外壁各鉸接有杠桿，杠桿的支點鉸接有支板，杠桿的另一端與聯動桿鉸接，聯動桿再與油缸的油缸軸鉸接；另外，在托板的一側還有一個托板定位器。
The vertical positioning mechanism bracket of the aluminum alloy door and window processing equipment is fixed on the plate support plate. There are two lifting cylinders under the support plate. The lifting cylinder is composed of the lifting cylinder guide sleeve of the guide shaft of the lifting cylinder. The bracket plate is fixed on the guide sleeve of the two lifting cylinder, and the outer wall of the two elevator guide sleeve is articulated with levers and bars. The support point of the rod is articulated with a supporting plate, the other end of the lever is articulated with the linkage rod, and the linkage rod is rehinged with the oil cylinder shaft of the oil cylinder. In addition, there is a plate positioner on the side of the bracket.

門窗傾斜問題：門窗在安裝完畢后，出現了傾斜、門扇走扇推拉不好的現象，這主要是由于安裝人員在安裝過程中沒有用線墜，靠尺檢查門窗與地面或臺面的垂直度，造成偏差過大。鋁合金門窗加工設備因此安裝門窗時，一定要按安裝規范去做。門窗不水平：門窗安裝后，出現一頭高一頭低、扇和框的縫隙不均勻現象，有時存在上寬下窄或下寬上窄的問題。

Door and window slant problem: after the installation of the door and window, there is a bad phenomenon of slanting and door fan, which is mainly due to the failure of the installation staff in the installation process, and the verticality of the doors and windows and the surface or the table is checked by the ruler, resulting in too much deviation. Aluminum alloy doors and windows processing equipment, so when installing windows and doors, we must follow the installation specifications. The doors and windows are not horizontal: after the doors and windows are installed, there is an uneven gap between the top and the bottom, the fan and the frame, and sometimes there is a problem of wide width, narrow width or narrow width.
處理這種問題，首先要測量窗臺或地面的水平度，看一下哪邊高，然后以高點為基準，低的地方用木楔或墊塊臨時固定，以調整窗框的水平度。水平度調好了，窗子就不會出現一邊高一邊低的現象。托板定位器是在步進電機的出軸上固定一垂直的絲杠，在絲杠上通過螺紋連接一個光電傳感器。
To deal with this problem, we should first measure the level of the windowsill or the ground, see which side is high, and then take the high point as the base, and the low places are temporarily fixed with the wedges or padding blocks to adjust the level of the window frame. When the level is adjusted, the window will not appear high and low. The supporting plate positioner is fixed with a vertical screw on the outlet shaft of the stepping motor, and a photoelectric sensor is connected to the screw rod through threads.
絲杠采用滾珠絲杠。玻璃鋁條切割裝置由擺臂、Ａ銷軸、夾緊塊、固定塊、鋸片、電機、連接板、Ａ氣缸、底板、支架、接頭、氣缸板、Ｂ氣缸、氣缸尾座、Ｂ銷軸、墊片和電機接頭組成。軟頭快速連接的裝置，包括燈罩、與帶電線的端子注塑為一體的軟頭，還包括緊套在燈罩尾端外的塑膠卡套，鋁合金門窗加工設備塑膠卡套的外表面上至少有一個凸起點，軟頭的內表面上有寬度與凸起點相適配的軸向?qū)虿奂芭c軸向?qū)虿鄞怪辈⑾嗤ǖ闹雇撇?。前出裝置包括平臺、傳送輥和支撐輪，平臺的兩端分別鉸接有轉板，兩轉板之間連接有橫梁，傳送輥設置于橫梁上；平臺與轉板之間設有一組活塞桿、氣缸作為轉板的驅動機構，活塞桿鉸接于平臺上，氣缸鉸接于轉板上。敲打門框要用塑錘輕輕地敲，切不可用鐵錘去敲。
The ball screw is best used for the screw. The glass aluminum strip cutting device consists of swinging arm, A pin shaft, clamping block, fixed block, saw blade, motor, connecting plate, A cylinder, floor, bracket, joint, cylinder board, B cylinder, cylinder tail seat, B pin shaft, gasket and motor joint. A device for fast connection with a soft head, including a light cover, a soft head that is injected into the terminal of a live line, and a plastic jacket that is tightened outside the end of the lamp cover. At least one convex starting point is on the outer surface of the plastic card sleeve of the aluminum alloy door and window processing equipment, and the inner surface of the soft head has an axial direction slot suitable for matching the convex starting point. A thrust slot that is perpendicular to the axial direction groove and interconnected. The fore out device includes the platform, the transmission roll and the supporting wheel. The two ends of the platform are articulated with a rotating plate respectively. The cross beam is connected between the two rotating plates. The transfer roller is set on the beam. A group of piston rods and cylinders are set between the platform and the rotating plate as the driving mechanism of the rotating plate. The piston rod is articulated on the Yu Ping platform, and the cylinder is articulated to the rotating plate. Knock the doorframe with a plastic hammer and knock it lightly.
