鋁型材切割機從名字是可以看出，這是一款切割鋁的設備，鋁由于不易生銹、質量輕、易加工被廣泛應用于門窗戶、幕墻、散熱器、各種裱框等，因此對切割加工工藝要求特別高，而鋁型材切割機的切割精度可達0.01mm。對鋁型材切割機鋸片的要求也是相當高，鋁型材切割機鋸片一般采用鑲硬質合金刀粒,鋸片主軸轉速2000-5000轉,鋁材切割機作用對像是切割鋁棒、鋁板、鋁管、鋁異型材.切割機用途很大的，但是如果將此精密設備來切割其他型材如鐵、不銹鋼、這些高硬度的材料，不劃算、不經濟，
Aluminum cutting machine can be seen from the name, this is an aluminum cutting equipment, aluminum because it is not easy to rust, light, easy to process is widely used in the door window, curtain wall, radiator, various framed and so on, so the cutting process requirements are very high, and the cutting precision of the aluminum profile cutting machine can reach 0.01mm. The requirements for the cutting machine of aluminum profile cutting machine are also very high. The blade of the aluminum profile cutting machine generally uses a hard alloy knife and 2000-5000 rotation of the spindle speed of the saw blade. The function of the aluminum cutting machine is like cutting aluminum bar, aluminum plate, aluminum tube and aluminum profile. The cutting machine is very useful, but if this precision equipment is used to cut the other sections, the cutting machine is used. Such as iron, stainless steel, these high hardness materials, not cost-effective, uneconomical,

鋁型材切割機價格相對于型材切割機來說高了很多，一臺氣動半自動鋁型材切割機一般價值0.8-1.5萬左右，而一臺型材切割機只需幾百上千元便可以，型材切割機屬于粗加工，它的功能是只需將一些型材切下來便可，無需對精度、和光滑度負責，而鋁型材切割機切出的鋁型材必須要求表面光滑、精度也要求十分精細，所以二者最好不要共用

The price of the aluminum profile cutting machine is much higher than that of the profile cutting machine. A pneumatic semi-automatic cutting machine is worth about 0.8-1.5 ten thousand, and a section cutting machine is only a few hundred thousand yuan. The cutting machine is a rough machining. The function of the cutting machine is only to cut some profiles off, without the precision of the precision. And the smoothness is responsible, and the aluminum profile cutting machine must require smooth surface and precision, so the two should not share it.
再者鋁型材由于材質原因，在切割過程中刀片高速旋轉，會產生熱量，而鋁材質軟容易被熱刀片熔化，所以在鋁型材切割機上裝有切屑油，這不僅起到潤滑刀片的作用，還有冷卻刀片的作用，所以價格上比起來也是相差大
Moreover, because of the material reason of the aluminum profile, the blade will rotate rapidly during the cutting process, which produces heat, and the aluminum material is easy to be melted by the hot blade, so the cutting oil is installed on the cutting machine of the aluminum profile, which not only plays the role of lubricating blade, but also the role of the cooling blade, which is also different in price.
通過以上，大家應該明白為什么鋁型材切割機和型材切割機不能共用了吧。因?yàn)樾筒那懈顧C(jī)不能當鋁材切割機使用，原因是型材切割機的角度尺不精確，在切鋼鐵型材時，切出的型材角度即使有較大的誤差，較大的接縫在焊接時可以用焊條彌補。但型材切割機切鋁材時，如果切出的鋁材角度誤差較大時，鋁材對接后就會出現較大的縫隙，這縫隙用緊固件是無法彌合的。
Through the above, we should understand why aluminum profiles cutting machine and profiles cutting machine can not share it. Because the cutting machine can not be used as an aluminum cutting machine, the reason is that the angle ruler of the section cutting machine is not accurate. When cutting the steel section, the section angle of the section has large error, and the larger joint can be made up with welding rod when welding. But when cutting the aluminum material of the cutting machine, if the angle error of the aluminum material cut out is large, the aluminum material will appear large gap after docking. This gap can not be bridged with the fastener.
