1.脈沖電參數的合理搭配：中走絲線切割加工時，較寬的脈沖寬度容易產生比較大的氧化鋁或表面粘有氧化鋁的顆粒，脈沖間隔過小的話也會產生較大的顆拉。而鉬絲上極易粘附這些較大的加工顆粒，給加工帶來很大的負面影響。提高脈沖電源的空載電壓幅值，通過降低脈沖寬度、加工脈沖間隙，可減少加工屑枯附到電極絲上的可能性。
The reasonable collocation of 1. pulse electric parameters: in the process of wire cutting, the wider pulse width is easier to produce larger alumina or particles with alumina on the surface, and a larger pull will be produced when the pulse interval is too small. On the other hand, it is very easy for the molybdenum wire to adhere to these larger processing particles. Increasing the amplitude of the no load voltage of the pulse power supply can reduce the possibility of processing scraps attached to the electrode wire by reducing the pulse width and processing pulse gap.

2.對工作液的要求：目前常采用水溶液作為中走絲線切割加工的工作液，寶瑪常規配置比例是1:30，而加工鋁型材料時，宜采用3:8的比例。為了保持工作液的清沽，使其正常有效地工作，并延長工作液的使用期，可使用厚的海綿，避免殘屑流人水箱，保持工作液的暢通，減少電極絲上加工屑的粘附。對海綿墊進行定期的清洗或更換。工作液的上下噴水量應均勻，以便及時把蝕除物排除。

2. to the requirements of the working fluid: at present, the water solution is often used as the working fluid for wire cutting, and the proportion of the routine allocation is 1:30, and the proportion of 3:8 should be used when the aluminum material is processed. In order to keep the work liquid clear, make it work normally and effectively, and prolong the use period of the working fluid, a thick sponge can be used to avoid the debris flow to the water tank, keep the working fluid unblocked and reduce the adhesion of the processing chips on the electrode wire. The sponge pad is regularly cleaned or replaced. The spray amount of the working fluid should be uniform, so as to remove the etch in time.
3.操作技巧：可在上線架后端槽中加一塊海綿，高速往返的電極絲經海綿摩擦，可去掉一部分粘附的氧化物，減少氧化物對導電塊的磨損，同時減少電極絲抖動，確保脈沖電源效率的正常發揮。還要注意勤更換導電塊的工作位置。
3. operation skills: a sponge can be added to the back end slot of the line frame. The electrode wire of high speed round-trip can be rubbed through the sponge, which can remove a part of the adhesive oxide, reduce the wear of the oxide to the conductive block, and reduce the jitter of the electrode wire at the same time, so as to ensure the normal use of the efficiency of the pulse power supply. It is also necessary to pay attention to the replacement of the working position of the conductive block.
有了鋁切割設備上面的小總結，希望對廣大客戶有所幫助，如果有什么不理解的或者尋求幫助的請點擊我們的官方網站：http://www.hnyfqpj.cn或者來電咨詢，我們會盡全力為您解決
With a small summary of the aluminum cutting equipment, we hope to be helpful to the customers. If there is anything that is not understood or for help, please click on our official website: http://www.hnyfqpj.cn or inquire, we will do our best to solve the problem.
